Symply LTO-7 Tape Data Cartridge
LTO-7 BaFe Data Cartridge With 6TB Native And 15TB Compressed Capacity
£ 63.95 | £ 76.74 inc VAT
SymplyDIT XTH Dual Bay – 1 x LTO-7 HH Fitted
SymplyDIT XTH Dual Bay – 1 x LTO-7 HH Fitted
Half-Height LTO-7 DIT Desktop Archive System With Dual Thunderbolt 3, 12Gb SAS And Two 2.5-Inch SSD Reader Bays
The SymplyPRO DIT XTH – LTO-7 is a purpose-built on-set and DIT archive system combining one half-height LTO-7 tape drive with two front 2.5-inch SATA SSD reader bays for ingest and transfer workflows.
It provides 6TB native / 15TB compressed per cartridge, with native tape throughput up to 300MB/s. Dual Thunderbolt 3 ports support daisy-chaining and device charging, while SAS Host and SAS Expansion ports provide 12Gb SAS connectivity through SFF-8644.
- One fitted half-height LTO drive in a chassis supporting one or two drives.
- Two 2.5-inch SATA SSD reader bays for DIT ingest workflows.
- 2 × Thunderbolt 3 plus SAS Host and SAS Expansion.
- LTFS, AES-256 hardware encryption and LTO WORM support.
- SymplyCABLELESS architecture for rapid drive servicing and expansion.
Original price was: £ 6,399.00.£ 6,013.95Current price is: £ 6,013.95. | £ 7,216.74 inc VAT
Please Call Us For Availability Of This Item
Please Call To Order
Category: LTO Tape Drives
Brand: Symply
SymplyDIT XTH Dual Bay – 1 x LTO-7 HH Fitted – Product Overview
The SymplyPRO DIT XTH - LTO-7 is designed specifically for production and post-production teams that need to ingest removable SSD media and create LTO archive copies from one compact desktop system. Symply combines professional LTO tape hardware with two front 2.5-inch SATA SSD reader bays that also support Atomos Master Caddy workflows.
Integrated DIT Ingest
Two front 2.5-inch SATA SSD reader bays bridge removable SSD media into the Thunderbolt workflow, allowing ingest, verification and tape archive tasks to be handled from a single unit.
Thunderbolt 3 And 12Gb SAS
Two Thunderbolt 3 ports support daisy-chaining, with one port providing up to 60W charging. Separate SAS Host and SAS Expansion connections use SFF-8644, allowing the unit to work with non-Thunderbolt SAS hosts or attach additional compatible SAS devices.
LTO-7 Capacity And Performance
The half-height LTO-7 mechanism provides 6TB native / 15TB compressed per cartridge and native throughput up to 300MB/s.
Expandable SymplyCABLELESS Architecture
The XTH chassis supports one or two half-height tape mechanisms. SymplyCABLELESS allows compatible drives to be removed, serviced or upgraded quickly and provides a straightforward path to adding a second drive.
LTFS And Data Protection
LTFS support enables file-based tape workflows, while AES-256 hardware encryption and LTO WORM media compatibility support secure long-term retention and offline archive strategies.
Professional Desktop Design
The all-metal enclosure includes a premium power supply and active cooling. Dimensions are approximately 30.0 × 21.1 × 13.6cm and weight is approximately 5.6kg.
Included For Deployment
Symply supplies the system with data and cleaning cartridges, a 2m active Thunderbolt 3 cable, SymplyLOCK and power cable. The product carries a 3-year Advanced Replacement warranty.
SymplyDIT XTH Dual Bay – 1 x LTO-7 HH Fitted – Key Features
- Purpose-built SymplyPRO DIT desktop archive and transfer system.
- 1 × half-height LTO-7 drive fitted in an expandable one/two-drive chassis.
- 6TB native / 15TB compressed per cartridge.
- Native tape throughput up to 300MB/s.
- 2 × front 2.5-inch SATA SSD reader bays for SSD and Atomos Master Caddy workflows.
- 2 × Thunderbolt 3 ports with daisy-chain support; one port supplies up to 60W charging.
- SAS Host and SAS Expansion via SFF-8644.
- SymplyCABLELESS architecture for fast servicing and drive expansion.
- LTFS support for file-based tape workflows.
- AES-256 hardware encryption and LTO WORM media support.
- All-metal enclosure with integrated PSU and active cooling.
- Data cartridge, cleaning cartridge, 2m active Thunderbolt 3 cable, SymplyLOCK and power cable included.
- 3-year Advanced Replacement warranty.
SymplyDIT XTH Dual Bay – 1 x LTO-7 HH Fitted – Technical Specifications
| Product Type | SymplyPRO DIT XTH Desktop LTO System |
| Drive Type | LTO-7 Half Height |
| LTO Drives | 1 Fitted; Chassis Supports 1 Or 2 Half-Height Drives |
| SSD Reader Bays | 2 × 2.5-Inch SATA SSD; Supports Drives Under 9mm And Atomos Master Caddy Workflows |
| Native Capacity | 6TB |
| Compressed Capacity | 15TB (2.5:1) |
| Native Tape Throughput | Up To 300MB/s |
| Thunderbolt | 2 × Thunderbolt 3; Daisy Chain; Up To 60W Charging On One Port |
| SAS Host | 1 × SFF-8644, 12Gb SAS |
| SAS Expansion | 1 × SFF-8644, 12Gb SAS |
| LTFS | Supported |
| Encryption | AES-256 Hardware Encryption |
| WORM | Supported |
| Dimensions | 30.0 × 21.1 × 13.6cm |
| Weight | Approx. 5.6kg |
| Included | Data Cartridge, Cleaning Cartridge, 2m Active Thunderbolt 3 Cable, SymplyLOCK, Power Cable |
| Warranty | 3-Year Advanced Replacement |
