ATTO FastFrame AIR N412 – Long Range

ATTO FastFrame AIR N412 – Long Range
ATTO FastFrame AIR N412 – Long Range - Image 2
ATTO FastFrame AIR N412 – Long Range - Image 3
ATTO FastFrame AIR N412 – Long Range

Dual-Port 100GbE PCIe 4.0 x16 SmartNIC With Advanced Heat Baffling And Long-Range QSFP28 Optics

The ATTO FastFrame AIR N412 – Long Range uses the same dual-port 100GbE N412-AIR SmartNIC platform as the standard optics version, but is supplied with long-range QSFP28 optics for extended-distance fibre connections.

Designed for high-performance workstations, it connects through PCIe 4.0 x16, supports 50/100GbE networking and delivers up to 100Gb/s throughput per port. ATTO’s Advanced Heat Baffling Technology provides dedicated thermal management where chassis airflow may be limited.

  • Dual-port 50/100GbE QSFP28 connectivity.
  • Long-range QSFP28 optics supplied instead of the standard optics.
  • Up to 100Gb/s throughput per port.
  • PCIe 4.0 x16 host interface.
  • RoCE, TCP/UDP/IP offloads and NVMe over Fabrics target offload at 100Gb.
Category: Ethernet NICs, Ethernet PCIe Cards
SKU: FFRM-N412-LRA
Brand: ATTO Technology

Original price was: £ 2,218.44.Current price is: £ 2,204.95. | £ 2,645.94 inc VAT

Please Call Us For Availability Of This Item

ATTO FastFrame AIR N412 – Long Range – Product Overview

The FastFrame AIR N412 – Long Range combines the proven N412-AIR 100GbE SmartNIC platform with long-range QSFP28 optics for installations requiring extended fibre reach. The underlying adapter hardware and performance specifications are the same as the standard N412-AIR configuration.

Long-Range Optical Configuration

This LRA version is supplied with long-range QSFP28 optics in place of the standard transceivers, while retaining the same dual-port N412-AIR card platform.

Dual-Port 100GbE Connectivity

The adapter supports 50GbE and 100GbE operation over QSFP28, with throughput of up to 100Gb/s per port.

PCIe 4.0 x16 Host Interface

A PCIe 4.0 x16 mechanical and electrical interface provides the host connection required for high-bandwidth workstation networking.

Advanced Networking Offloads

ATTO lists RDMA over Converged Ethernet together with TCP, UDP and IP stateless offloads and built-in hardware offloads. NVMe over Fabrics target offload is supported on the 100Gb model.

Workstation-Friendly Thermal Design

Advanced Heat Baffling Technology is designed to maintain airflow around the adapter in constrained workstation environments. The card uses a low-profile, half-height, three-quarter-length form factor, with ATTO listing macOS, Windows and Linux support.

ATTO FastFrame AIR N412 – Long Range – Key Features

  • Same N412-AIR SmartNIC hardware as the standard optics version.
  • Long-range QSFP28 optics supplied instead of standard optics.
  • Dual-port 50/100GbE connectivity.
  • Up to 100Gb/s throughput per port.
  • PCIe 4.0 x16 mechanical and electrical host interface.
  • Advanced Heat Baffling Technology.
  • Low-profile, half-height, three-quarter-length form factor.
  • RDMA over Converged Ethernet.
  • TCP/UDP/IP stateless offloads and built-in hardware offloads.
  • NVMe over Fabrics target offload at 100Gb.
  • macOS, Windows and Linux support.
  • Three-year standard product warranty.

ATTO FastFrame AIR N412 – Long Range – Technical Specifications

ModelATTO FastFrame AIR N412 – Long Range
SKUFFRM-N412-LRA
Card PlatformN412-AIR
Ethernet Ports2
Supported Ethernet Speeds50GbE / 100GbE
Maximum ThroughputUp to 100Gb/s per port
Optical InterfaceQSFP28
Included OpticsLong-range QSFP28 optics
Host InterfacePCIe 4.0 x16, mechanical and electrical
CoolingAdvanced Heat Baffling Technology
Form FactorLow profile; half height, three-quarter length
Networking FeaturesRoCE; TCP/UDP/IP stateless offloads; built-in hardware offloads
Storage Networking OffloadNVMe over Fabrics target offload at 100Gb
Operating SystemsmacOS, Windows, Linux
Warranty3 years

ATTO FastFrame AIR N412 – Long Range Product Downloads

ATTO FastFrame AIR N412 – Long Range Product Datasheet >>
