ATTO ThunderLink FC-3322 LR

ATTO ThunderLink FC-3322 LR
ATTO ThunderLink FC-3322 LR - Image 2
ATTO ThunderLink FC-3322 LR - Image 3
ATTO ThunderLink FC-3322 LR

Dual-Port Thunderbolt 3 To 32Gb Fibre Channel Adapter — 2 x Long-Range Single-Mode LC SFP+ Transceivers Included

The ATTO ThunderLink FC-3322 LR is the long-range single-mode optical variant of ATTO’s dual-port 32Gb Fibre Channel ThunderLink adapter.

It provides two 32Gb Fibre Channel SFP+ LC ports with long-range optics and two 40Gb/s Thunderbolt USB-C connections.

  • 2 x 32Gb Fibre Channel SFP+ LC ports.
  • Long-range single-mode SFP+ optics included.
  • 2 x 40Gb/s Thunderbolt USB-C ports.
  • 32/16/8Gb Fibre Channel auto-negotiation.
Category: Fibre Channel HBAs, Thunderbolt Adapters
SKU: TLFC-3322-LE0
Brand: ATTO Technology

Original price was: £ 4,287.45.Current price is: £ 4,203.95. | £ 5,044.74 inc VAT

Please Call Us For Availability Of This Item

ATTO ThunderLink FC-3322 LR – Product Overview

Long-Range Dual-Port 32Gb Fibre Channel

The FC-3322 LR supports long-distance single-mode Fibre Channel connectivity for Thunderbolt-enabled workstations and shared storage environments.

32Gb Fibre Channel

The adapter auto-negotiates at 32Gb, 16Gb and 8Gb and supports point-to-point and direct fabric/switch attach.

Thunderbolt Host Compatibility

ATTO's current FC-3322 specification supports Thunderbolt 5, 4 and 3 host environments through two 40Gb/s Thunderbolt USB-C connections.

ATTO SAN Features

FC Class 3 operation, 80 buffer credits, adaptive load balancing, NPIV and Virtual Fabric support high-performance SAN workflows.

ATTO ThunderLink FC-3322 LR – Key Features

  • Two 32Gb Fibre Channel SFP+ LC ports.
  • Long-range single-mode SFP+ optics included.
  • Auto-negotiates to 32Gb, 16Gb and 8Gb Fibre Channel.
  • Dual 40Gb/s Thunderbolt USB-C ports.
  • Current ATTO specification supports Thunderbolt 5 / 4 / 3 hosts.
  • Point-to-point and direct fabric/switch attach support.
  • FC Class 3 support.
  • 80 buffer credits.
  • Adaptive load balancing.
  • Three-year standard warranty.

ATTO ThunderLink FC-3322 LR – Technical Specifications

ModelATTO ThunderLink FC-3322 LR
SKUTLFC-3322-LE0
Thunderbolt Interface2 x 40Gb/s Thunderbolt USB-C
Host CompatibilityThunderbolt 5 / 4 / 3 supported by current ATTO specification
Fibre Channel Ports2 x 32Gb/s
ConnectorSFP+ LC optical
Included OpticsLong-range single-mode SFP+ optics
Supported Fibre Channel Speeds32Gb, 16Gb, 8Gb
TopologyPoint-to-point; direct fabric/switch attach
Fibre Channel ClassClass 3
Buffer Credits80
Dimensions8.66 x 4.07 x 1.20 in
Power Adapter Output12VDC
Warranty3 years

ATTO ThunderLink FC-3322 LR Product Downloads

ATTO ThunderLink FC-3322 LR Product Datasheet >>
