ATTO ThunderLink FC-3162 LR
(2 x LR Single Mode LC SFP+ Included)

 Home All Products To Buy All Networking Equipment Fibre Channel HBAs ATTO ThunderLink FC-3162 LR (2 x LR Single Mode LC SFP+ Included)

ATTO ThunderLink FC-3162 LR
(2 x LR Single Mode LC SFP+ Included)

Dual-Port Thunderbolt™ 5/4/3 To Dual-Port 16Gb Fibre Channel Adapter With Long Range Single Mode SFP+

The ATTO ThunderLink FC 3162 (TLFC-3162-LE0) is a high-performance external adapter that connects Thunderbolt-enabled workstations to 16Gb/s Fibre Channel networks and storage devices using long-range single mode optics.

This specialized model features dual 16Gb Fibre Channel ports with included long-range single mode LC SFP+ modules, designed for extended distance connectivity requirements in professional media and IT environments.

  • Dual 16Gb/s Fibre Channel ports with long-range single mode SFP+ modules included.
  • Compatible with Thunderbolt 5/4/3 interfaces offering up to 40Gb/s bandwidth.
  • Supports advanced failover and load balancing through ATTO’s exclusive MultiPath Director technology.
  • Enables simultaneous 4K video file transfer and display capabilities.

Original price was: £ 2,668.08.Current price is: £ 2,580.95.

Please Call Us For Availability Of This Item

Category: Fibre Channel HBAs, Thunderbolt Adapters
SKU: TLFC-3162-LE0
Brand: ATTO Technology

ATTO ThunderLink FC-3162 LR (2 x LR Single Mode LC SFP+ Included) – Product Overview

The ATTO ThunderLink FC 3162 (TLFC-3162-LE0) serves as a critical bridge between Thunderbolt-enabled workstations and 16Gb/s Fibre Channel storage infrastructure, specifically designed with long-range single mode optics for extended distance connectivity requirements.

This specialized adapter leverages Thunderbolt technology's impressive 40Gb/s bandwidth to deliver exceptional performance for data-intensive workflows in media production, healthcare imaging, and enterprise environments.

The TLFC-3162-LE0 variant comes equipped with dual long-range single mode LC SFP+ modules, enabling connectivity over significantly greater distances than standard multimode optics—ideal for campus environments or facilities with widely distributed equipment.


Advanced Connectivity Architecture

The dual-port configuration provides redundant paths to storage, ensuring continuous operation even if one connection fails.

ATTO's exclusive MultiPath Director technology enables sophisticated failover and load balancing capabilities, maintaining optimal performance and reliability in mission-critical environments.

The adapter auto-negotiates to 16Gb and 8Gb devices, providing backward compatibility with existing Fibre Channel infrastructure while enabling future expansion.


Optimized for Media & Entertainment

Creative professionals benefit from the adapter's ability to simultaneously support 4K video file transfer and display through the Thunderbolt 3 interface.

The high-bandwidth, low-latency connection is ideal for real-time editing of uncompressed video content directly from shared storage.

ATTO's Advanced Data Streaming (ADS) Technology maximizes CPU processes to deliver smooth and reliable data transfers with consistent high performance.


Enterprise-Grade Reliability

With over 30 years of experience developing storage connectivity solutions, ATTO has engineered the ThunderLink FC 3162 to meet the demands of 24/7 operation in critical production environments.

Each adapter undergoes rigorous testing and certification with major storage and workstation manufacturers to ensure seamless integration and compatibility.

The included long-range single mode optics have been specifically selected and tested to ensure data integrity over extended distances.


Flexible Deployment Options

The external form factor allows for easy installation without requiring internal access to workstations or laptops.

Thunderbolt's daisy-chaining capability enables connection of up to five additional Thunderbolt-enabled devices through a single port.

The adapter supports both macOS and Windows operating systems, providing cross-platform flexibility for diverse work environments.


Management and Monitoring

ATTO's intuitive ConfigTool software provides comprehensive management, monitoring, and configuration capabilities.

Administrators can easily track performance metrics, update firmware, and adjust settings to optimize the adapter for specific workflow requirements.

The software's user-friendly interface simplifies complex storage connectivity management, reducing IT overhead and maximizing productivity.

ATTO ThunderLink FC-3162 LR (2 x LR Single Mode LC SFP+ Included) – Key Features

  • Dual 16Gb/s Fibre Channel ports with long-range single mode LC SFP+ modules included for extended distance connectivity.
  • Thunderbolt interface with 40Gb/s bandwidth, compatible with Thunderbolt 5/4/3 devices.
  • Supports 4K video file transfer and display simultaneously through Thunderbolt 3 technology.
  • ATTO's exclusive MultiPath Director technology provides advanced failover and load balancing capabilities.
  • Advanced Data Streaming (ADS) Technology maximizes CPU processes for smooth and reliable data transfers.
  • Auto-negotiates to 16Gb and 8Gb Fibre Channel devices for backward compatibility.
  • Ability to daisy-chain up to five additional Thunderbolt technology-enabled devices.
  • Compatible with macOS, Windows, and Linux operating systems.
  • Supports ATTO 360 Tuning, Monitoring and Analytics Software for optimized performance.
  • Kensington Security Slot for additional physical security via Kensington Lock.
  • TAA Compliant with country of origin: USA.
  • RoHS Compliant for environmental sustainability.
  • Comprehensive three-year standard product warranty.

ATTO ThunderLink FC-3162 LR (2 x LR Single Mode LC SFP+ Included) – Technical Specifications

Model NumberTLFC-3162-LE0
Form FactorDesktop
Input Connectors(2) 40Gb/s Thunderbolt™
Output Connectors(2) 16Gb/s Fibre Channel
Connector TypeSFP+ LC Optical
Optical ModulesLong Range Single Mode SFP+
Data Transfer RateUp to 32Gb/s throughput per port
Auto Negotiation16Gb, 8Gb
Thunderbolt VersionCompatible with Thunderbolt 5/4/3
Thunderbolt Ports2
DisplayPort SupportYes
Daisy Chain SupportUp to 5 additional Thunderbolt devices
Operating SystemsmacOS, Windows, Linux
PowerSelf Powered
Power CordBS 1363 UK 10 power cord
Dimensions (WxHxD)10.3 cm x 3.05 cm x 22 cm
Advanced FeaturesMultiPath Director, Advanced Data Streaming (ADS) Technology
Management SoftwareATTO ConfigTool, ATTO 360
Security FeaturesKensington Security Slot
ComplianceClass B/EN55024, EN60825-1, EN60825-2, IEC62368-1, cTUVus, EU RoHS (2002/95/EC), (EU) 2015/863, TAA Compliant
Country of OriginUSA
Warranty3 Years

ATTO ThunderLink FC-3162 LR (2 x LR Single Mode LC SFP+ Included) – Product Downloads
