Areca ARC-8050T3U-6M SSD RAID Array – Unpopulated
Small, Very Fast, Expandable 6-Bay Thunderbolt 3 and USB 3.2 Gen 2 Hardware SSD RAID Array with Display Port (No Drives Fitted)
The Areca ARC-8050T3U-6M provides a 6-bay desktop RAID enclosure designed for 2.5-inch 12Gb/s SAS or 6Gb/s SATA SSDs, supporting high-speed Thunderbolt 3 connectivity up to 40Gbps.
It features dual Thunderbolt 3 ports for daisy-chaining and a DisplayPort for video output, with hardware RAID levels including 0, 1, 10, 3, 5, 6, 30, 50, 60, single disk, and JBOD.
Equipped with a dual-core 1.2GHz SAS ROC and 2GB DDR3-1866 SDRAM cache, it delivers enterprise-grade performance for video editing and data-intensive workflows.
- Supports macOS 10.12+ and Windows 8/10+ via Thunderbolt 3; OS-independent USB 3.2 Gen 2 mode.
- Configuration via Thunderbolt, LAN, or LCD panel.
- Includes 1m active Thunderbolt 3 cable and intelligent power management.
- Expansion port for additional enclosures up to 256 drives.
Original price was: £ 1,690.00.£ 1,399.95Current price is: £ 1,399.95. | £ 1,679.94 inc VAT
Please Call Us For Availability Of This Item
Category: Desktop Hard Drives & RAIDs
Brand: Areca Technology
We’re the UK’s #1 Areca Reseller!
We pride ourselves on knowing, selling and supporting Areca RAIDs & Controllers better than anyone else in the UK!
All our Areca RAIDs ship pre-configured & tested (RAID5 or RAID6, for Mac or PC). Please allow us 1-2 days to do this for you for free.
Seen a better price elsewhere? Let us know & we’ll do our best so you also benefit from our Areca knowledge, expertise & totally free after-sales support.
– The UK Areca RAID Experts!
Areca ARC-8050T3U-6M SSD RAID Array – Unpopulated Product Overview
The Areca ARC-8050T3U-6M is a 6-bay desktop RAID storage enclosure optimized for 2.5-inch SSDs, delivering Thunderbolt 3 connectivity at 40Gbps for high-performance data access in professional environments.
It supports both Thunderbolt 3 and USB 3.2 Gen 2 protocols, enabling seamless use with Thunderbolt-equipped hosts or USB-C systems, while providing daisy-chaining and DisplayPort video output.
Hardware RAID Capabilities
The unit employs a dual-core 1.2GHz LSI/Broadcom SAS2308 ROC with 2GB DDR3-1866 SDRAM cache featuring ECC protection for reliable operation.
RAID levels include 0, 1, 10, 3, 5, 6, 30, 50, 60, single disk, and JBOD, with features like online array roaming, RAID level migration, and up to 1MB stripe size.
Connectivity and Compatibility
Two Thunderbolt 3 ports allow host connection and peripheral daisy-chaining with power delivery for notebooks; a full-size DisplayPort 1.4 supports 8K@30Hz output.
USB fallback mode activates via USB-C, supporting USB 3.2 Gen 2 speeds; full Apple M1 silicon compatibility ensures broad macOS and Windows support.
Drive and Expansion Support
Accommodates up to six 2.5-inch 12Gb/s SAS or 6Gb/s SATA HDDs/SSDs; includes an SFF-8644 expansion port for connecting up to seven additional enclosures, supporting 256 drives total.
Controller-level hardware encryption, SED support, and batch firmware updates enhance data security and maintenance.
Configuration and Management
Setup occurs via Thunderbolt/LAN ports or front LCD panel; intelligent power on/off protects data integrity during operations.
Video-optimized settings and simultaneous 4K workflows cater to creative professionals.
Physical Design
Desktop form factor measures 4.84 x 8.45 x 9.11 inches with dual 2700rpm cooling fans and 180W power supply; weighs 13.2 lbs empty.
Areca ARC-8050T3U-6M SSD RAID Array – Unpopulated Key Features
- 40Gbps Thunderbolt 3 interface with dual ports for host connection, daisy-chaining, and notebook power delivery.
- DisplayPort 1.4 output supporting 8K@30Hz or dual 4K UHD displays.
- Dual-core 1.2GHz SAS ROC with 2GB DDR3-1866 ECC SDRAM cache for hardware RAID processing.
- Supports 6 x 2.5-inch 12Gb/s SAS or 6Gb/s SATA SSDs/HDDs in unpopulated configuration.
- RAID levels: 0, 1, 10, 3, 5, 6, 30, 50, 60, single disk, JBOD with online migration and roaming.
- SFF-8644 expansion port for up to 256 drives across enclosures.
- USB 3.2 Gen 2 compatibility mode for non-Thunderbolt hosts.
- Apple M1 silicon support and OS-independent USB operation.
- Configuration via Thunderbolt, LAN, or LCD; includes 1m active Thunderbolt 3 cable.
- Controller encryption, SED support, batch drive firmware updates, and intelligent power management.
- Dual 2700rpm fans, 180W PSU in 4.84 x 8.45 x 9.11-inch desktop chassis weighing 13.2 lbs.
Areca ARC-8050T3U-6M SSD RAID Array – Unpopulated Technical Specifications
| Form Factor | Desktop 6-Bay |
| Connection | Thunderbolt 3 x 2, DisplayPort x 1 |
| Computer Port Type | Thunderbolt 3, USB 3.2 Gen 2 |
| Disk Ports | 6 x 12Gb/s SAS or 6Gb/s SATA (2.5-inch HDD/SSD) |
| I/O Processor | Dual Core 1.2 GHz SAS ROC (LSI SAS2308) |
| On-Board Cache | 2GB DDR3-1866 SDRAM with ECC |
| RAID Levels | 0, 1, 10, 3, 5, 6, 30, 50, 60, Single Disk, JBOD |
| RAID Features | Online array roaming, RAID level/stripe migration, up to 1MB stripe, multiple RAID selection |
| Expansion Support | SFF-8644 (2-lanes), up to 7 enclosures (256 drives max) |
| Cooling | 2 x 2700rpm fans |
| Power Supply | 180W internal |
| Dimensions (W x H x D) | 4.84 x 8.45 x 9.11 in (146 x 255 x 290 mm) |
| Weight | 13.2 lbs / 6.0 Kg (unpopulated) |
| XLR | 4-pin XLR |
| OS Support | Thunderbolt 3: macOS 10.12+, Windows 8/10+; USB: OS Independent |
| Additional Features | Hardware encryption, SED support, batch firmware update, video-optimized settings, intelligent power on/off |
| Included Accessories | 1m 40Gb/s active Thunderbolt 3 (USB-C) cable |
| Configuration Methods | Thunderbolt/LAN port, LCD panel |
